YS5706
Smart Relay
4.6123 reviews
R$ 247,00
R$ 290,00
In stock
Switch a compatible circuit through one normally open, voltage-free relay contact pair, controlled in the YoLink app.
Before you buy
A YoLink hub and a separate 5–24 V DC supply capable of at least 300 mA are needed; sold separately.
Important information
Install indoors in a dry enclosure. Relay contacts do not supply power or overcurrent protection; use a suitable protected circuit.
Product details
Switch a compatible circuit through one normally open, voltage-free relay contact pair, controlled in the YoLink app.
Specifications
- Switched load rating
- Up to 5 A at 120 V AC or 30 V DC (normally open dry contacts)
- Power source
- External DC supply
- Power input
- 5–24 V DC; external supply capable of ≥300 mA
- Power connector
- DC+ and DC− input terminals
- Operating temperature
- −4–122°F (−20–50°C)
- Operating humidity
- 5–85% RH, non-condensing
- Dimensions
- 53 × 49 × 25 mm (2.09 × 1.93 × 0.98 in)(L × W × D)
What’s in the box
In the box: 1 × YoLink Relay (YS5706); 1 × Quick Start Guide
Manuals & support
Shipping, returns & warranty
Returns
60-day returns from delivery. Customer-paid return shipping; condition and restocking terms apply.
Return policy
