- "X3" (commercial grade) smart wireless outdoor-rated valve controller and outdoor-rated motorized valve kit
This store requires javascript to be enabled for some features to work correctly.
INTRODUCTION:
FEATURES:
- Controller does not require external power - no AC, plug/receptacle, wiring, required.
- Remote status and control with the convenient YoLink app
- YoLink Control allows for the Water Valve Controller to be controlled directly by YoLink Water Leak Sensor 2, without an internet connection
- YoLink’s industry-leading long range communication allows for operation in larger homes and in areas difficult for other wireless systems, such as basements, separate garages/structures, and even outside your home
- Amazon/Google Assistant, Home Assistant and IFTTT integration
- 2 Year Warranty on the controller and valve (Typically, mechanical products carry a 1 year warranty, unless purchased as part of an X3 controller kit)
BENEFITS:
- Remotely check on the on/off status of your valves, using the YoLink app
- The extended environmental range allows for outdoor use in some climates and applications (refer to Technical Specs, below, and to the installation manual for more information)
- Extremely easy and fast installation using the YoLink app with Scan & Play
- As part of your long-range/low-power YoLink smart home system, enjoy the reliability and carefree operation with Water Valve Controller batteries that can last 10 or more years
APPLICATIONS:
- Remotely turn the water on or off at your condo, rental property, summer/winter home while not in use
- Prevent unauthorized use, by turning off water lines
- Use the YoLink Water Leak Sensor to automatically shut off the water when a leak is detected, preventing costly damages (Water Leak Sensor sold separately)
- Shut off water to your lawn sprinkler system during the winter months, preventing water from freezing in the pipes
- Automate pet and livestock watering, with remote control and preset schedules (consider pairing your water valve controller with the Water Leak Sensor 2 with water level detection)
- Connect the valve to HPT Hose Pipe Fittings, to connect to and control garden hoses, for control of lawn sprinklers and swimming pool water level (consider our Water Level Monitoring Sensor, for automatic water level top-off systems)
TECHNICAL SPECIFICATIONS:
TECHNICAL SPECS (CONTROLLER):
Controller: Semtech® LoRa® RF Module YL09 microcontroller with 32-Bit RISC processor
Visual Interface: Multi-color Status LED
User Controls: SET Button
Power: One ER34615 3.6V lithium battery (replaceable)
IP Rating: IP67
Environmental:
Operating Temperature Range: -4°F – 122°F (-20°C – 50°C)
TECHNICAL SPECS (MOTORIZED VALVE):
Voltage: DC 12V
Applicable Water Pipe Size: (Same as Valve Size)
Thread: NPT
Indicator: Yes
Valve Body Material: Stainless Steel
Actuator Material: Engineering Plastics
Open/Closed Time: Less Than 5 Sec
Suitable Media: Air, Water
Max. Torque Force For Actuator: 2 N.M
Cable Length: 0.5 Meters
Max Working Pressure: 145PSI (1.0MPA)
Working Current: Max 500Ma While in Operation (Opening or Closing; no Current Draw in Standby Mode)
Environmental:
Liquid Temperature Range: 35.6° to 194°F (2° to 90°C)
Environment Temperature Range: -5 to 122F (-15° to 50°C)
DATASHEET:
DATASHEET:
WHAT'S IN THE BOX?
- (1) YoLink X3 Water Valve Controller
- (1) DN##S Motorized Valve
- (1) Quick Start Guide
USER GUIDE:
REQUIREMENTS:
- YoLink Hub with an internet connection (wired Ethernet or 2.4GHz Wi-Fi). Refer to the Hub user guide for additional information
- Smartphone or tablet running iOS 9 or higher, Android 4.4 or higher
- Tools Required: None
- Installation Difficulty Level: Super Easy
RELATED INFORMATION & PAGES:
If you have not already visited these pages, please do so. If any of our product information is found to be insufficient or if you have any remaining questions, please use the Contact Us area near the bottom of this page. Click or tap for more info:
Start Here: Hubs & Starter Kits
Water Control
Leak Protection System Builder
REQUIRED PRODUCTS (HUB):
For full functionality, including for the app to work, YoLink devices must connect to at least one hub (YoLink Hub or SpeakerHub), and that hub must have an internet connection. Unless you are adding devices to an existing YoLink account, or unless your building is covered by an existing YoLink or Raedius wireless network, please add one hub to your order.
SUGGESTED PRODUCTS:
After your Hub or SpeakerHub is set-up and online, you are ready to add water leak detection, siren alarms, or any of our growing line of long-range, long-life and economical smart products! Please consider adding our water leak detection sensors, can can easily be added to your system, and can complete your Smart Water Leak Protection System. Click here to learn more.
Consider the FlexFob, for remote control of your valve!
RELATED OR SIMILAR PRODUCTS:
FREQUENTLY-ASKED QUESTIONS:
Q: Can I manually operate the valve? A: Yes. The valve has a manual operation knob on the top. On the underside of the sensor, after removing the waterproof screw hole plugs, remove the four screws to access the battery area. The sensor uses two AAA batteries, standard alkaline (lithium is optional), but do not use rechargeable batteries. You should get upwards of 5 years between battery changes!
Q: Do I need the hub? A: Yes. For full functionality, and for the app to work, the Valve Controller must wirelessly connect to one of our hubs (the original YoLink Hub or the SpeakerHub - learn more here) that has an internet connection. It is possible to use Control-D2D pairing to establish links between your sensors, such as between the valve controller and leak sensors, so that the devices will operate - the valve controller will shut off the water automatically upon water detection - even if the power is out and the internet is down, but this is as a back-up or protection against those situations. For the app to work, including remote viewing and controlling of your YoLink devices, device health checks, battery level, and firmware updates from the factory, you should have a hub.
